BLUEOPTICS SFP-1G-LH-TL-BO verkkolähetin-vastaanotinmoduuli, kuitu, 1250 Mbit/s

The BLUEOPTICS SFP-1G-LH-TL-BO is a high-performance SFP transceiver module designed for long-haul single-mode fiber optic networks. It operates at a data rate of 1.25 Gbps and supports distances up to 10 km using BiDi WDM technology. This module is hot-pluggable and fully compliant with IEEE 802.3z and SFP MSA standards, ensuring seamless integration with TP-Link JetStream switches, Omada routers, and media converters.

Advantages

This transceiver offers reliable, high-speed connectivity for enterprise and data center environments. Its BiDi design reduces fiber usage by transmitting and receiving on different wavelengths over a single fiber, lowering infrastructure costs. With DDM/DOM support, network administrators can monitor real-time parameters for proactive maintenance.

Suitable for

• TP-Link JetStream switches
• Omada routers
• Media converters
• Any SFP-compatible networking equipment requiring 1.25 Gbps single-mode fiber links up to 10 km

Key specifications

• Module Type: SFP
• Data Rate: 1.25 Gbps
• Transmission Mode: Bi-Directional (BiDi) WDM
• Fiber Type: Single-Mode Fiber (SMF)
• Connector Type: LC Simplex
• Wavelength (Tx): 1310 nm
• Wavelength (Rx): 1550 nm
• Max Cable Distance: 10 km
• DDM/DOM Support: Yes
• Hot-Pluggable: Yes
• Power Supply: 3.3V
• Operating Temperature: 0°C to 70°C
• Storage Temperature: -40°C to 85°C
• Standards: IEEE 802.3z, SFP MSA
• Laser Type: FP Laser
• Receiver Type: PIN Photo Detector

Recommendations

For optimal performance, use with high-quality single-mode fiber patch cables and ensure proper cleaning of LC connectors. This module is ideal for extending network reach in campus, metropolitan, and enterprise networks.
