EFB Elektronik INFRALAN I-B(ZN)BH 4x12G 50/125µm OM4 LSZH erika violetti CPR-B2CA

The EFB Elektronik INFRALAN I-B(ZN)BH 4x12G 50/125µm OM4 LSZH Erica Violet CPR-B2CA is a high-performance indoor/outdoor fibre optic cable designed for demanding network infrastructures. With 4 fibres of 12G OM4 grade, it supports high-speed data transmission up to 100 Gb/s over short distances. The cable features a low smoke zero halogen (LSZH) jacket, ensuring safety in enclosed spaces, and is CPR B2ca rated for fire performance. Its erika-violet colour provides easy identification.

Advantages

This cable offers excellent bandwidth and reliability for data centres, enterprise networks, and campus backbones. The OM4 multimode fibre optimises 850nm VCSEL sources for high-speed Ethernet. The LSZH jacket reduces toxic fumes in case of fire, and the CPR B2ca certification ensures compliance with European construction regulations.

Suitable for

• Data centre interconnects
• Enterprise LAN backbones
• Fibre-to-the-desk (FTTD) installations
• Industrial environments requiring low smoke and flame retardancy

Key specifications

• Brand: EFB Elektronik
• Model: 56348.2OM4-CPR
• Fibre type: OM4 multimode 50/125µm
• Number of fibres: 4
• Jacket material: LSZH (Low Smoke Zero Halogen)
• Colour: Erica Violet
• CPR class: B2ca
• Standards: ISO/IEC 11801, EN 50173

Recommendations

For optimal performance, pair with OM4-rated connectors and patch panels. Ensure proper cable management to maintain bend radius. Suitable for indoor and protected outdoor installations.
