ELTAKO 22100731 3-johdin vipuliitäntäliitin, 32 A, 450 V, läpinäkyvä/oranssi

The ELTAKO 22100731 lever-operated splicing connector makes solid, stranded, and fine-stranded conductor connections without tools. Its lever mechanism holds wires securely and releases them just as easily, which speeds up installation and rework in junction boxes, luminaires, and control cabinets. The transparent housing gives a clear view of the contact point, while the orange actuation levers are easy to identify and operate even in tight spaces.

Highlights

• Tool-free lever operation for fast, reliable connections
• Accepts solid, stranded, and fine-stranded conductors from 0.14 to 4 mm² (AWG 24-12)
• Rated for 450 V and 32 A according to EN standards
• Compact transparent polycarbonate housing with orange PA66 levers
• Operating temperature range from -20 °C to +85 °C

In daily use

Electricians and panel builders value this connector for its quick wiring and secure clamping. The 9–10 mm stripping length is clearly marked on the housing, reducing preparation errors. The single-potential design keeps installations tidy, and the UL 94 V-2 flammability rating supports use in a wide range of electrical enclosures.

Full specifications

• Number of conductors: 3
• Connection type: Lever-operated splicing connector
• Rated voltage (EN): 450 V
• Rated current (EN): 32 A
• Wire size (solid/stranded): 0.2–4 mm² (AWG 24-12)
• Wire size (fine-stranded): 0.14–4 mm² (AWG 24-12)
• Stripping length: 9–10 mm
• Housing material: Polycarbonate (PC)
• Actuation lever material: Polyamide 66 (PA66)
• Contact material: Electrolytic copper (E Cu)
• Colour: Transparent / Orange
• Operating temperature: -20 to +85 °C
• Pollution degree: 2
• Flammability rating: UL 94 V-2
• Approvals: CE, UL, VDE, ENEC
• Mounting type: Free wiring
• Total number of potentials: 1

Final note

The ELTAKO 22100731 combines tool-free convenience with a broad conductor range, making it a dependable choice for professional electrical work.
