Gembird Cablexpert MWS-2S6-01 pistorasia RJ45 Cat.6 uppoasennuskannella valkoinen

The Gembird Cablexpert MWS-2S6-01 is a flush-mount wall socket outlet combining two Schuko power sockets (Type F, CEE 7/3) with one RJ45 Cat.6 unshielded network port. Designed for residential and office environments, this integrated unit simplifies installation by combining power and data connectivity in a single white ABS plastic wall plate.

Advantages

Space-saving design reduces clutter by merging power and network outlets in one flush-mount plate. Easy termination of the RJ45 port via LSA (IDC) terminals supporting TIA/EIA 568A/B wiring standards. The white finish blends seamlessly with standard interior decor.

Suitable for

• Home offices requiring both power and network access at the same location
• Commercial workstations where desk or wall space is limited
• New installations or retrofits in standard flush-mount boxes

Key specifications

• Product Type: Wall Socket Outlet
• Power Outlets: 2x Schuko (Type F, CEE 7/3)
• Network Ports: 1x RJ45 Cat.6 UTP
• Mounting: Flush mount (Unterputz)
• Colour: White
• Material: ABS Plastic
• Max. Power Rating: 250V AC, 16A
• RJ45 Termination: LSA (IDC) terminals
• Wiring Standard: TIA/EIA 568A/B
• Operating Temperature: -10°C to 60°C
• Humidity: 10% to 90% RH non-condensing
• Certifications: CE, RoHS

Recommendations

For best performance, use with Cat.6 or higher patch cables. Ensure proper termination of the RJ45 module according to T568A or T568B standards. Suitable for indoor use only.
