Gira 5562000 IP-kameramoduuli System 106 G musta

The Gira 5562000 IP Camera Module for System 106 G is a high-performance color camera with day/night function, designed for seamless integration into Gira System 106 flush-mounted or surface-mounted housings. This module delivers HD resolution (1280 x 960 pixels) and features a 1/3" CMOS sensor, H.264 video compression, and a wide dynamic range (WDR) for clear images in challenging lighting conditions. With Power over Ethernet (PoE) support and an IP54 protection rating when installed, it is ideal for professional surveillance applications.

Advantages

High-definition video quality with day/night automatic switching ensures round-the-clock monitoring. The wide dynamic range (WDR) enhances image clarity in high-contrast scenes. Easy installation via PoE eliminates the need for separate power cabling. The robust zinc die-cast housing and IP54 rating provide durability and weather resistance.

Suitable for

• Indoor and outdoor security surveillance
• Integration into Gira System 106 building automation
• Residential and commercial property monitoring

Key specifications

• Image sensor: 1/3" CMOS
• Resolution: 1280 x 960 pixels (HD)
• Video compression: H.264
• Horizontal field of view: approx. 90°
• Vertical field of view: approx. 70°
• Minimum illumination: 0.5 lux (color), 0.1 lux (B/W)
• Special features: WDR, automatic day/night switch, IR cut filter
• Network interface: Ethernet (RJ45)
• Power supply: Power over Ethernet (PoE) IEEE 802.3af Class 0
• Material: Zinc die-cast
• Color: Black (RAL 9005)
• Protection class: IP54 (when installed)
• Operating temperature: -25 °C to +70 °C
• Mounting: Modular component for Gira System 106 housings
• Mechanical angle adjustment: +/- 15° (horizontal/vertical)

Recommendations

For optimal performance, pair this camera module with a compatible Gira System 106 housing and a PoE switch. Ensure proper installation to maintain IP54 protection.
