GRAFENTHAL verkkokaapeli CAT6 S/FTP CU 0,5 m harmaa

The GRAFENTHAL Patch Cable CAT6 S/FTP CU is a high-performance network cable designed for reliable data transmission in demanding environments. With a length of 0.5 meters, it is ideal for short-distance connections between network devices such as switches, routers, and patch panels. The cable features S/FTP shielding (Screened Foiled Twisted Pair) to protect against electromagnetic interference, ensuring stable and fast data transfer.

Advantages

This patch cable offers excellent signal integrity and reduced crosstalk thanks to its S/FTP shielding and stranded copper conductors. The gold-plated RJ45 connectors provide corrosion resistance and optimal conductivity. The snagless molded boot protects the connector tabs from damage during installation and removal. Compliant with CAT6 standards, it supports bandwidth up to 250 MHz and data rates up to 10 Gbps for short distances.

Suitable for

• Connecting computers to network switches or routers
• Patch panel to switch connections in data centers
• Home and office LAN networks
• 10GBASE-T applications over short distances

Key specifications

• Cable Type: Patch Cable
• Category: CAT6
• Shielding: S/FTP (PiMF)
• Conductor Material: Copper (CU)
• Conductor Construction: Stranded
• Conductor Gauge: AWG 26/7
• Cable Length: 0.5 m
• Connector Type: RJ45 (8P8C)
• Connector Plating: Gold-plated (50µm)
• Boot Type: Snagless, Molded
• Jacket Material: PVC
• Color: Grey
• Bandwidth: Up to 250 MHz
• Data Transfer Rate: Up to 10 Gbps
• Wiring Standard: TIA/EIA 568B
• Outer Diameter: Approx. 6.0 mm
• Flame Retardancy: IEC 60332-1
• Operating Temperature: -20°C to +60°C
• Compliance: RoHS, CE

Recommendations

For optimal performance, use this cable with CAT6-compatible devices and avoid sharp bends or kinks during installation. Ensure connectors are fully seated to maintain signal integrity.
