Lanview LVN126105 seinä-/katkaisimen peitelevy valkoinen

The Lanview LVN126105 wall plate provides a screwless, low-profile finish for network installations. It accepts a single RJ45 keystone module mounted at an angled orientation to reduce cable bend radius and minimize required back box depth. The plate includes a protected text window for an ID label and is finished in white, with compact dimensions of 50 mm × 75 mm and a lightweight design.

Advantages

The angled RJ45 keystone orientation reduces stress on cables and helps maintain signal integrity by lowering the bend radius. Its screwless design offers a clean, modern appearance suitable for visible installations. The integrated protected text window allows clear ID labeling without exposing the label to wear.

Suitable for

• Residential network wall outlets
• Office or commercial LAN ports
• Installations with shallow back boxes or limited mounting depth
• Environments requiring visible, neatly labeled ports

Key specifications

• Brand: Lanview
• Model: LVN126105
• Color: White
• Compatible module: Single RJ45 keystone (angled)
• Dimensions: 50 mm × 75 mm
• Weight: 19.5 g
• Package contents: 1 piece
• MPN: LVN126105
• EAN: 5704174318736

How to use

Turn off network devices if required and mount the wall plate onto the wall box according to local electrical codes. Insert a compatible RJ45 keystone module into the angled opening, terminate the network cable on the keystone jack following standard wiring schemes, label the protected text window, then secure the plate in place. The angled orientation helps route the cable smoothly toward the back box.

Recommendations

For best results, use an RJ45 keystone compatible with the plate and follow recommended cable bend-radius guidelines. The angled design is particularly useful where the back box is shallow or where you want to reduce cable stress; do not force excessively sharp bends when terminating cables.
