Lanview LVO230501-MTP InfiniBand/kuitu-kaapeli 1 m violetti

The Lanview LVO230501-MTP InfiniBand fibre optic cable is a 1 m OM4 multimode patch cord with MTP connectors on both ends and a 50/125 µm core/cladding construction. It provides full-duplex multi-mode connectivity for high-speed networking, supporting 10G/40G/100G Ethernet and InfiniBand links commonly used in data centres, server rooms and high-density cabling environments. The cable uses an LSZH jacket and meets common industry standards for multimode fibre performance.

Advantages

This OM4 MTP cable offers improved bandwidth and longer reach compared with lower-grade multimode fibres, making it suitable for 40G and 100G applications. The precision-moulded MT ferrule and guide pins ensure accurate alignment of fibre cores for low insertion loss. The LSZH jacket reduces smoke and toxic emissions in case of fire and the cable is RoHS compliant, supporting safe deployment in data centres and industrial facilities.

Suitable for

• 10G/40G/100G Ethernet connections
• InfiniBand high-speed links
• Data centre and server-to-switch cabling
• QSFP+, SFP+ and BIDI SR transceiver connections

Key specifications

• Brand: Lanview
• Model / MPN: LVO230501-MTP
• Length: 1 m
• Fibre type: OM4 multimode (50/125 µm)
• Connector: MTP Female — MTP Female (both ends)
• Duplex: Full duplex multi-mode
• Jacket material: LSZH (Low Smoke Zero Halogen)
• Colour: Violet
• EAN: 5704174870869

How to use

Inspect connector endfaces before installation and clean if necessary with appropriate fibre cleaning tools. Plug each MTP connector into the corresponding MTP adapter or transceiver port, ensuring correct orientation and secure seating. Route the cable following recommended bend radius guidelines to avoid signal degradation. For multi-rack installations, label both ends for easy identification and verify the link with appropriate fibre test equipment after installation.

Recommendations

Use this OM4 MTP 1 m cable in controlled cabling pathways and structured panels. Avoid tight bends and excessive pulling force during installation, and use dust caps when connectors are not mated to protect endfaces and maintain low insertion loss.
