MEAN WELL IRM-10-12 AC/DC-virtalähde 10,2W 12V 0,85A valettu PCB-asennusmoduuli musta

In industrial control cabinets and compact automation systems, the MEAN WELL IRM-10-12 delivers reliable 12V DC power from a universal AC input. This encapsulated PCB-mount module is a go-to for engineers integrating low-power electronics into space-constrained designs.

Key specifications

• Output: 12 VDC, 0.85 A, 10.2 W
• Input: 85–264 VAC (120–370 VDC)
• Efficiency: 82%
• Ripple & noise: 120 mVp-p
• No-load power consumption: <0.1 W
• Protection: short circuit, overload, over voltage
• Isolation: 3000 VAC
• Operating temperature: -30 to +70 °C
• MTBF: 1,495,800 hours
• Mounting: PCB through-hole
• Form factor: encapsulated module, black housing
• Safety: UL62368-1, TUV EN62368-1, EAC TP TC 004, CE

Why choose it

The IRM-10-12 combines a wide input range with a fully encapsulated design, offering protection against dust, moisture, and vibration. Its low standby draw and high MTBF make it a dependable choice for always-on applications.

Ideal use cases

• Industrial sensors and controllers
• IoT gateways and smart devices
• Building automation systems
• Test and measurement equipment
• LED lighting drivers

Good to know

Free air convection cooling eliminates the need for fans, ensuring silent operation. The module meets international safety standards, simplifying compliance for global products.
