MEAN WELL SPBW03G-05 3W DC-DC-muunninmoduuli 5V 600mA 9-18V tulo DIP24

This DC-DC converter module delivers a regulated 5V output at 600mA from a 9-18V input, making it a reliable power solution for industrial and embedded systems. Its 2:1 wide input range and 1500VDC isolation ensure stable performance in demanding environments.

Advantages

The SPBW03G-05 features high efficiency up to 80%, low ripple and noise (50mVp-p), and excellent line/load regulation (±0.5%). It operates over a wide temperature range from -40°C to +85°C with free air convection cooling, and includes short circuit and overload protection for enhanced reliability.

Suitable for

• Industrial control systems
• Telecommunication equipment
• Battery-powered devices
• Distributed power architectures
• Test and measurement instruments

Key specifications

• Input voltage: 9-18 VDC (2:1 range)
• Output: 5 VDC, 600 mA, 3 W
• Isolation: 1500 VDC
• Efficiency: 80% typical
• Ripple & noise: 50 mVp-p max
• Operating temperature: -40 to +85 °C
• Package: DIP24, through-hole mounting
• MTBF: >1,000,000 hours

Recommendations

For optimal performance, ensure adequate airflow around the module and keep input voltage within the specified range. Use proper PCB layout techniques to minimize noise coupling and maintain isolation integrity.
