MEAN WELL SPV-150-24 150W 24V 6.25A yhden lähdön teollisuusteholähde PFC:llä

The MEAN WELL SPV-150-24 stands apart from typical industrial power supplies by combining a robust 150W output with a built-in active PFC function in a compact metal case. This unit delivers a stable 24V DC at up to 6.25A, making it a dependable choice for demanding automation, LED lighting, and industrial control applications. Unlike many competitors in its class, it operates with free air convection cooling, eliminating the need for a fan and ensuring silent, maintenance-free operation even in dusty or vibration-prone environments.

Highlights

• 150W single output with adjustable voltage from 21.6V to 28.8V
• Built-in active PFC for improved power factor and compliance with EN61000-3-2
• Wide input voltage range: 90~264VAC or 127~370VDC
• Protections: short circuit, overload, over voltage, over temperature
• Convection cooled – no fan, silent operation
• High efficiency up to 88% and low ripple & noise (150mVp-p max.)
• Safety approvals: UL60950-1, TUV EN60950-1
• MTBF > 200K hours

In daily use

Installation is straightforward thanks to the standard terminal block connections and compact dimensions. The adjustable output voltage allows fine-tuning for specific load requirements, while the wide operating temperature range from -20°C to +65°C ensures reliable performance in harsh conditions. The metal case provides excellent heat dissipation and mechanical protection, and the unit can be mounted on a DIN rail or directly onto a panel using the provided mounting holes. Whether powering sensors, motors, or communication equipment, the SPV-150-24 delivers consistent, clean DC power with minimal electrical noise.

Full specifications

• Output voltage: 24V DC (adjustable 21.6~28.8V)
• Output current: 6.25A
• Rated power: 150W
• Input voltage: 90~264VAC / 127~370VDC
• Input frequency: 47~63Hz
• Efficiency: 88% (typ.)
• Ripple & noise: 150mVp-p max.
• Setup, rise time: 1000ms, 50ms at 230VAC full load
• Protections: Short circuit, overload, over voltage, over temperature
• Operating temperature: -20~+65°C
• Cooling: Free air convection
• Safety standards: UL60950-1, TUV EN60950-1
• EMC standards: EN55022 Class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11
• Isolation voltage (input-output): 3kVAC
• Housing: Metal case
• MTBF: >200K hrs min.

Final note

The MEAN WELL SPV-150-24 is a proven workhorse for industrial applications where reliability and silent operation are paramount. Its active PFC and comprehensive protections make it a future-proof choice for system integrators and OEMs.
