METZ CONNECT BTR ruuvattu kaapeliläpivienti M25 2x8 - nikkelöity messinki, IP68

The METZ CONNECT BTR Screwed Cable Gland M25 2x8 is a high-quality industrial cable entry solution designed for reliable sealing and strain relief in demanding environments. With a metric M25 thread and dual cable entries accommodating 4.0-8.0 mm diameter cables, this gland ensures secure connections for data networks and industrial applications.

Advantages

Nickel-plated brass construction offers excellent corrosion resistance and durability. The NBR seal provides IP68 protection against dust and water ingress, with pressure resistance up to 10 bar. Wide operating temperature range (-40°C to +100°C) ensures performance in extreme conditions.

Suitable for

• Industrial control cabinets and junction boxes
• Data network installations
• Sensor and actuator connections
• Automation and process control systems

Key specifications

• Thread size: M25 x 1.5
• Number of cable entries: 2
• Cable diameter range: 4.0 - 8.0 mm per entry
• Material: Nickel-plated brass
• Seal material: NBR (Nitrile Rubber)
• Protection class: IP68
• Pressure resistance: Up to 10 bar
• Operating temperature: -40°C to +100°C
• Mounting hole diameter: 25.2 mm
• Thread length: 10 mm
• Wrench size: 30 mm
• Color: Metallic (Nickel)
• Strain relief: Yes

Recommendations

For optimal performance, ensure the cable gland is properly tightened to the specified torque and that cables are within the recommended diameter range. Suitable for use with METZ CONNECT patch panels and distribution boxes.
