NEO TOOLS Neo 35-015 digitaalinen yleismittari CAT II 600V taustavalolla ja Data Hold -toiminnolla

Electrical troubleshooting demands precise measurements and reliable safety. The NEO TOOLS Neo 35-015 digital multimeter answers that need with a robust CAT II 600V rating, manual ranging, and a full set of measurement functions for voltage, current, resistance, diode, and continuity. Its backlit LCD and data hold function make readings easy even in dim or awkward positions, while overload protection and a low battery indicator ensure dependable operation on the job.

Who is it for

This multimeter is built for electricians, electronics hobbyists, HVAC technicians, and automotive DIYers who need a straightforward, portable instrument for everyday diagnostics. It is equally at home in a service van, on a workbench, or in a tool bag for field service calls.

Main features

• Manual ranging digital multimeter with 3½-digit LCD (max display 1999)
• Measures DC voltage (200mV–600V), AC voltage (200V/600V), DC current (200µA–10A), and resistance (200Ω–2MΩ)
• Diode test and audible continuity buzzer for quick checks
• Data hold freezes the reading on screen for convenient recording
• Backlit display improves visibility in low-light environments
• Overload protection and low battery indicator for safe, dependable use
• Powered by a standard 9V (6F22) battery (not included)
• Safety rated CAT II 600V for residential and light commercial circuits

Specifications

• Display: LCD, 3½ digits, max count 1999
• DC voltage ranges: 200mV / 2V / 20V / 200V / 600V (±0.5% basic accuracy)
• AC voltage ranges: 200V / 600V (±1.2% basic accuracy)
• DC current ranges: 200µA / 2mA / 20mA / 200mA / 10A (±1.2% basic accuracy)
• Resistance ranges: 200Ω / 2kΩ / 20kΩ / 200kΩ / 2MΩ (±1.0% basic accuracy)
• Input impedance (DCV): 1MΩ
• Diode test: yes (forward voltage drop)
• Continuity test: yes (buzzer sounds below approx. 50Ω)
• Data hold: yes
• Backlight: yes
• Ranging: manual
• Power supply: 9V battery, type 6F22 (not included)
• Low battery indicator: yes
• Overload protection: yes
• Safety rating: CAT II 600V
• Operating temperature: 0°C to 40°C (32°F to 104°F)
• Storage temperature: -10°C to 50°C (14°F to 122°F)

Tips

Always select the highest range first when measuring unknown values to protect the meter. For current measurements, move the red test lead to the 10A jack when expecting currents above 200mA. Replace the battery when the low battery symbol appears to maintain accuracy. Store the meter in a dry place and remove the battery if it will not be used for extended periods.
