Seinäkiinnitteinen kaappi Extralink EX.12912 12U harmaa

EXTRALINK two-section rack cabinet - AZH, 12U, 600 × 600 is a wall-mounted network cabinet designed for offices, server rooms and CCTV control rooms. The cabinet body is made of cold-rolled steel and the front door is tempered glass that can be opened to the left or right. The two-section design provides easier rear access to mounted equipment. Vertical rails are clearly marked for 12U mounting and the cabinet total height is 640 mm. Side panels have snap fasteners for quick removal and the cabinet includes locks and keys. The ceiling contains two fan mounting positions and two cable grommets to improve cooling and cable routing.

Advantages

The EXTRALINK 12U wall-mounted cabinet combines a compact 12U form factor with a robust cold-rolled steel construction and a tempered glass front door for visibility. Marked vertical rails simplify precise equipment mounting, while snap-fastened side panels allow fast access during installation and maintenance. Integrated lockable doors increase physical security, and the ceiling fan cutouts with cable grommets support improved airflow and tidy cable management. Its grey finish fits both home and office environments.

Suitable for

• Small server racks and network switches in office environments
• CCTV and surveillance equipment installations
• Telecom or network patching points on walls
• IT equipment installations where rear access and space saving are required

Key specifications

• Rack capacity: 12U
• Height: 640 mm
• Width: 600 mm
• Depth: 750 mm
• Maximum load capacity: 60 kg
• Material: cold-rolled steel with tempered glass front door
• Colour: Grey
• Lock: included (locks and keys)

How to use

Mount the cabinet securely to a suitable wall structure following local installation standards, ensuring the wall and fixings support the maximum load. Install equipment into the marked 12U vertical rails and secure devices with standard 19" rack screws. Use the removable side panels for access during installation and maintenance. Fit fans to the two ceiling positions if additional airflow is required and route cables through the provided grommets to keep cable runs organised.

Recommendations

Install the cabinet on a load-bearing wall and verify mounting anchors for the combined weight of the cabinet and installed equipment. Allow adequate ventilation and, if necessary, install fans in the ceiling cutouts to maintain safe operating temperatures for active equipment.
