Telegärtner J08071A0048 LC Duplex OM4 monimuotokuituliitin, violetti, keraaminen ferrule, 1 kpl

The Telegärtner J08071A0048 is a high-quality LC Duplex fiber optic connector designed for multi-mode OM4 applications. Featuring a violet plastic housing and a zirconia ceramic ferrule, this field-installable connector ensures reliable performance in LAN, SAN, data centers, and FTTx environments. With typical insertion loss below 0.2 dB and return loss above 20 dB, it meets IEC 61754-20 and TIA/EIA-604-10 standards. Each pack contains one piece.

Advantages

This connector offers low insertion loss and high return loss for optimal signal integrity. The durable plastic housing (PBT, UL94-V0) and ceramic ferrule provide long-lasting performance, while the field-installable design simplifies on-site termination. It supports over 500 mating cycles and operates in a wide temperature range from -40°C to +85°C.

Suitable for

• Local Area Networks (LAN)
• Storage Area Networks (SAN)
• Data Centers
• FTTx installations
• Fiber optic patch panels and pigtails

Key specifications

• Connector Type: LC Duplex
• Fiber Type: Multi-Mode (OM4)
• Fiber Diameter: 50/125 µm
• Ferrule Material: Zirconia Ceramic
• Housing Material: Plastic (PBT, UL94-V0)
• Polishing Type: PC (Physical Contact)
• Insertion Loss (Typical): < 0.2 dB
• Return Loss (Typical): > 20 dB
• Operating Temperature: -40°C to +85°C
• Mating Cycles: > 500
• Standards: IEC 61754-20, TIA/EIA-604-10
• Quantity per Pack: 1 piece

Recommendations

For optimal performance, use with OM4 multimode fiber cables and ensure proper cleaning before installation. This connector is ideal for high-density data center applications where reliability and low loss are critical.
