Valaistustarvike MEAN WELL LPV-100-24 valkoinen 90-264V AC

The MEAN WELL LPV-100-24 is a compact constant-voltage lighting accessory designed to operate from a universal AC input of 90–264V (47–63Hz). Housed in a fully encapsulated, fully isolated plastic case with IP67 protection, this unit delivers a stable 24V DC output for LED lighting and moving sign applications. With dimensions of 190 × 37 × 52 mm and a 2-year warranty, it is intended for reliable, low-cost power delivery in indoor and outdoor installations where IP67-rated protection and surge resistance are required.

Advantages

The LPV-100-24 features a constant-voltage design with universal AC input and is fully encapsulated to IP67 standards for protection against dust and water. It withstands a 300VAC surge for 5 seconds and includes protections against short circuit, overload and overvoltage. Cooling is achieved by free air convection, and each unit undergoes a 100% full-load burn-in test to ensure reliability. The fully isolated plastic case provides extra safety for lighting installations.

Suitable for

• LED strip and module lighting
• LED drivers for signage and moving signs
• Indoor and outdoor lighting installations requiring IP67 protection

Key specifications

• Brand: mean well
• Model: LPV-100-24
• Input voltage: 90–264V AC, 47–63Hz
• Output: constant 24V DC
• Dimensions: 190 × 37 × 52 mm
• Protection class: IP67 (fully encapsulated)
• Surge withstand: 300VAC for 5 seconds
• Protections: short circuit, overload, over voltage
• Cooling: free air convection
• Warranty: 2 years

How to use

Install the LPV-100-24 in a location with adequate ventilation and where the IP67 enclosure is appropriate for the environment. Connect the AC input (90–264V) according to local electrical codes and then connect the 24V DC output to the LED lighting or signage load, observing correct polarity. Ensure wiring, fuses, and connectors are rated for the operating current and follow manufacturer instructions for secure mounting and cable entry to maintain IP67 protection.

Recommendations

Use within the specified input voltage and frequency range, provide adequate ventilation for heat dissipation, and protect the unit from prolonged exposure to temperatures or conditions outside the manufacturer’s specified range. For installations with high inrush or repeated surges, verify system-level surge protection despite the unit’s ability to withstand 300VAC for short durations.
