Victron Energy VE.Bus Smart Bluetooth -dongle ASS030572050

Managing and monitoring Victron inverter/chargers without a physical control panel or wired connection can be a challenge, especially in tight installation spaces. The Victron Energy VE.Bus Smart Bluetooth Dongle (ASS030572050) solves this by adding wireless Bluetooth connectivity to any VE.Bus device, enabling direct configuration and real-time monitoring from a smartphone or tablet using the free VictronConnect app.

Who is it for

This dongle is ideal for installers, boat owners, RV enthusiasts, and off-grid solar users who need convenient access to their Victron MultiPlus or Quattro inverter/chargers. It is also perfect for system integrators who want to commission or troubleshoot VE.Bus devices without a laptop or additional cables.

Main features

• Adds Bluetooth Smart (BLE) connectivity to any VE.Bus device
• Works seamlessly with the VictronConnect app for iOS and Android
• Supports battery temperature and voltage sensing via auxiliary inputs
• Powered directly from the VE.Bus port – no external power supply needed
• Compact, surface-mountable design with IP20 protection
• Firmware updates possible via VictronConnect
• Low power consumption (< 10 mA)

Specifications

• Product type: VE.Bus Communication Interface
• Wireless protocol: Bluetooth Smart (Bluetooth LE)
• App integration: VictronConnect
• Supported devices: VE.Bus inverter/chargers (MultiPlus, Quattro)
• Auxiliary input 1: Battery temperature sensor
• Auxiliary input 2: Battery voltage sensor
• Voltage sensing range: 0 - 70 VDC
• Temperature sensing range: -20 to +50 °C
• Power supply: Via VE.Bus port
• Current consumption: < 10 mA
• Operating temperature: -20 to +50 °C
• Enclosure protection: IP20
• Mounting type: Surface mount

Tips

For best Bluetooth range, mount the dongle in a location with minimal metal obstructions. Use the auxiliary inputs to monitor battery temperature and voltage for enhanced charging accuracy and safety. Always update the dongle firmware via VictronConnect to ensure compatibility with the latest inverter/charger features.
