Virtalähde MEAN WELL DPAN02E-05 2 W 5 V 0,2 A RoHS

The MEAN WELL DPAN02E-05 is a compact PCB-mount DC-DC converter designed for applications requiring a small, low-power dual output supply. It accepts an input voltage range of 4.5–9 VDC and provides dual ±5 V outputs rated at 0.2 A each. Supplied in a SIP through-hole package, the module delivers up to 2 W of output power and meets RoHS environmental standards.

Advantages

This DC-DC converter offers a compact footprint suitable for PCB mounting, dual isolated ±5 V outputs for symmetric supply needs, and reliable regulation at low power levels. Its SIP through-hole package simplifies assembly on standard printed circuit boards, and RoHS compliance ensures reduced environmental impact.

Suitable for

• Low-power embedded systems and microcontroller boards
• Signal conditioning and analog circuits requiring ±5 V rails
• Sensor modules and small industrial controls
• Prototyping and compact electronic assemblies

Key specifications

• Manufacturer: MEAN WELL
• Model (MPN): DPAN02E-05
• Input voltage: 4.5–9 V DC
• Output: Dual ±5 V DC
• Output current: 0.2 A per output
• Output power: 2 W
• Package: SIP through-hole
• Standards: RoHS compliant

How to use

Mount the DPAN02E-05 into the PCB using the SIP through-hole pins and ensure correct orientation for input and output connections. Apply a stable DC input within 4.5–9 V and verify polarity before powering. Connect the ±5 V outputs to the load, observing the 0.2 A current limit per rail. Provide appropriate decoupling capacitors on the PCB if required by the application and follow the manufacturer’s layout recommendations for grounding and thermal considerations.

Recommendations

The unit is intended for low-power applications; avoid exceeding the rated input range and per-output current to maintain reliable operation. Use the module on properly designed PCBs with adequate spacing and grounding to minimise noise and ensure stable ±5 V rails.
