Virtalähde MEAN WELL SPAN02E-15 2W 15V 0,134A RoHS

The MEAN WELL SPAN02E-15 is a compact DC-DC converter designed for PCB mounting in a SIP through-hole package. It accepts an input voltage range of 4.5–9 V DC and provides a single regulated 15 V DC output at up to 0.134 A, with an output power of 2 W. The unit is RoHS compliant and intended for use where a small, board-mounted 15 V supply is required.

Advantages

The SPAN02E-15 offers a small footprint and through-hole SIP packaging for easy PCB integration. Its fixed 15 V output and 2 W power rating provide a simple solution for low-power circuits. RoHS compliance ensures the adapter meets common environmental and safety requirements for electronic assemblies.

Suitable for

• Embedded electronics and control boards
• Signal conditioning and sensor modules
• Small instrumentation and measurement circuits
• Battery-powered devices requiring a regulated 15 V rail

Key specifications

• Brand: mean well
• Model / MPN: SPAN02E-15
• Input voltage: 4.5–9 V DC
• Output: 15 V DC, 0.134 A (2 W)
• Package: SIP through-hole (PCB mount)
• RoHS: compliant
• EAN: 4021087041003

How to use

Mount the SPAN02E-15 into the PCB using the SIP through-hole pins and solder securely. Connect the input source within the specified 4.5–9 V DC range to the input pins and take the regulated 15 V DC from the output pins. Verify correct polarity and observe recommended soldering practices. Ensure the board layout provides adequate clearance and thermal conduction for reliable operation at the rated current.

Recommendations

Use the converter within its input voltage and output current limits; avoid operating continuously at maximum ratings without appropriate thermal management. Add input filtering and external capacitors on the PCB if required by the application to reduce noise and improve stability.
