Virtasovitin MEAN WELL SPAN02C-12 2W 12V tulo 36-75V

The MEAN WELL SPAN02C-12 is a compact DC-DC converter designed for PCB mounting. It accepts a wide input voltage range of 36–75 VDC and delivers a single regulated 12 VDC output at up to 0.167 A (2 W total). Packaged in a SIP through-hole form factor, this RoHS-compliant module is intended for use where a small, board-mounted isolated or non-isolated 12 V supply is required.

Advantages

The SPAN02C-12 provides a stable 12 V output across a broad input range, in a compact 2 W SIP through-hole package suitable for direct PCB installation. Its RoHS compliance ensures reduced environmental impact and suitability for regulated markets. The converter’s simple single-output design and small footprint simplify integration into space-constrained electronic systems.

Suitable for

• Embedded systems and PCB-based power rails
• Industrial control modules with 36–75 V supply buses
• Telecommunications equipment and instrumentation
• Prototyping and small-scale power conversion tasks

Key specifications

• Manufacturer: mean well
• Model (MPN): SPAN02C-12
• Input voltage: 36–75 VDC
• Output voltage: 12 VDC
• Output current: 0.167 A
• Output power: 2 W
• Package: SIP through-hole (PCB mount)
• Compliance: RoHS
• EAN: 4021087041058

How to use

Mount the SPAN02C-12 on the PCB using the SIP through-hole pins and solder according to standard PCB assembly practices. Connect the input to a DC source within 36–75 VDC and take the regulated 12 VDC output from the designated output pins. Observe correct polarity when wiring and follow the board layout recommendations from MEAN WELL for thermal management and isolation if required by your application.

Recommendations

Use the module within its specified input range and rated output current to ensure reliable operation. Provide adequate spacing and, if necessary, heat dissipation paths on the PCB. Verify compatibility with your system’s grounding and isolation requirements before final installation.
