BCS 5MP IP turret-kamera BCS-P-TIP25FSR4L4-Ai2(2)

The BCS 5MP IP Turret Camera BCS-P-TIP25FSR4L4-Ai2(2) is a high-performance surveillance solution designed for professional security applications. Featuring a 5-megapixel resolution and advanced AI analytics, this camera delivers crisp, detailed images and intelligent event detection. Its robust turret design ensures durability and flexibility in various indoor and outdoor environments.

Advantages

With 5MP resolution, the camera provides superior image clarity, enabling precise identification of objects and individuals. The built-in AI capabilities (Ai2) enhance security by reducing false alarms through intelligent motion detection, line crossing, and intrusion detection. The IR illumination with a range of up to 30 meters ensures 24/7 monitoring even in complete darkness. The camera supports PoE (Power over Ethernet) for easy installation with a single cable, and its IP67 weatherproof rating makes it suitable for outdoor use.

Suitable for

• Perimeter surveillance of commercial and residential properties
• Retail stores, warehouses, and parking lots
• Office buildings and educational institutions
• Industrial sites and critical infrastructure

Key specifications

• Brand: BCS
• Model: BCS-P-TIP25FSR4L4-Ai2(2)
• MPN: 1765511
• EAN: 5904890714502
• Category: IP Surveillance Camera
• Maximum Resolution: 5 MP (2592x1944)
• Sensor: 1/2.7" Progressive Scan CMOS
• Lens: 4mm fixed lens
• IR Range: Up to 30m
• Minimum Illumination: 0.01 Lux (color), 0 Lux with IR
• Day/Night: ICR (Infrared Cut Filter)
• Video Compression: H.265+/H.265/H.264+/H.264
• Frame Rate: 20fps@5MP, 25/30fps@4MP and lower
• AI Features: Intrusion detection, line crossing, motion detection
• Network Interface: 1x RJ45 10/100Mbps PoE
• Protocols: TCP/IP, UDP, HTTP, DHCP, NTP, RTSP, etc.
• Power Supply: PoE (802.3af) or 12V DC
• Power Consumption: ≤8W
• Operating Temperature: -30°C to +60°C
• Storage Temperature: -40°C to +70°C
• Ingress Protection: IP67
• Dimensions: Φ110mm x 95mm
• Weight: 0.5 kg

Recommendations

For optimal performance, use a PoE switch or injector compliant with IEEE 802.3af. Ensure the camera is mounted at a height of 2.5-5 meters for best coverage. Pair with a compatible NVR or VMS software for full AI functionality.
