EXSYS EX-1445 Gigabit Ethernet -jatkosarja 2-johtimisen yli, 500 m, musta

Gigabit Ethernet Extender Kit that transmits 10/100/1000 Mbps data over a single twisted pair cable up to 500 meters. Ideal for extending network connectivity using existing telephone or alarm wiring without installing new Ethernet cabling.

Advantages

Extends Gigabit Ethernet over long distances using low-cost twisted pair cable. Supports auto MDI/MDI-X and full-duplex operation, ensuring reliable performance. Metal housing and wall-mountable design provide durability and flexible installation.

Suitable for

• Connecting remote IP cameras, access points, or industrial devices
• Leveraging existing telephone or alarm cable infrastructure
• Extending network links in buildings where new cabling is impractical

Key specifications

• Data transfer rate: 10/100/1000 Mbps (Gigabit Ethernet)
• Maximum extension distance: 500 meters
• Transmission medium: Single twisted pair cable
• Ethernet ports: 1x RJ45 per unit
• Twisted pair ports: 1x Terminal Block per unit
• Power supply: External DC 12V/1A adapter (2 included)
• LED indicators: Power, Ethernet Link/Activity, Twisted Pair Link/Activity
• Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
• Features: Auto MDI/MDI-X, Full-Duplex, Plug & Play
• Housing material: Metal
• Operating temperature: 0°C to 50°C
• Storage temperature: -20°C to 70°C
• Operating humidity: 10% to 90% RH (non-condensing)
• Mounting: Wall-mountable
• Kit contents: 1x Transmitter, 1x Receiver, 2x Power Adapters, Manual

Recommendations

For reliable long-distance Ethernet extension using existing twisted pair wiring, this kit offers plug-and-play installation and robust metal housing.
