GRAFENTHAL patch-kaapeli CAT6 S/FTP CU 0,5 m harmaa LSZH Snagless RJ45

The GRAFENTHAL Patch Cable CAT6 S/FTP CU is a high-performance Ethernet cable designed for reliable network connections in professional environments. With a length of 0.5 meters, it is ideal for short-distance patching in server rooms, data centers, and office networks. The cable features S/FTP shielding (screened foiled twisted pair) to minimize electromagnetic interference, ensuring stable data transmission up to 1 Gbps.

Advantages

This patch cable offers excellent signal integrity and durability. The LSZH (Low Smoke Zero Halogen) jacket ensures safety in case of fire, making it suitable for public and commercial buildings. The snagless boot protects the RJ45 connectors during installation and removal, while the gold-plated contacts (50µm) provide corrosion resistance and reliable connectivity.

Suitable for

• LAN and Ethernet networks
• Connecting computers, switches, routers, and patch panels
• Data centers and server rooms
• Office and home networking

Key specifications

• Cable Type: Patch Cable
• Category: CAT6
• Shielding: S/FTP
• Conductor Material: Copper (CU)
• Conductor Gauge: AWG 26/7 (Stranded)
• Jacket Material: LSZH
• Connectors: RJ45 Male to Male
• Wiring Standard: TIA/EIA 568B
• Length: 0.5 m
• Color: Grey
• Bandwidth: Up to 250 MHz
• Data Transfer Rate: Up to 1000 Mbps
• Contact Plating: Gold-plated (50µm)
• Boot Type: Snagless
• Outer Diameter: Approx. 6.2 mm
• Flame Retardancy: Yes (IEC 60332-1-2)
• Halogen-free: Yes (IEC 60754-2)
• Operating Temperature: -20°C to +60°C

Recommendations

For optimal performance, use this cable with CAT6 compatible devices. Ensure proper cable management to avoid kinking or sharp bends. This cable is not recommended for outdoor use.
