HellermannTyton 401-58980 kaapelikanava, musta, 1 m, M25, PA6

Flexible cable conduit made of polyamide 6 (PA6) in black, designed for protecting and routing cables in demanding environments. With a nominal diameter of 21 mm and compatible with M25 threads, this conduit offers high flexibility and impact resistance, making it suitable for dynamic applications.

Advantages

High flexibility and impact resistance; self-extinguishing (UL94 V2); halogen-free; good UV and chemical resistance; wide operating temperature range from -40 °C to +120 °C (short-term up to +150 °C).

Suitable for

• Machine building and plant engineering
• Automotive and transportation
• Renewable energy installations
• Outdoor and UV-exposed environments

Key specifications

• Material: Polyamide 6 (PA6)
• Colour: Black
• Nominal diameter: 21 mm
• Outer diameter: 25.0 mm
• Inner diameter: 17.0 mm
• Thread size: M25
• Length: 1 m
• Operating temperature: -40 °C to +120 °C
• Short-term temperature: +150 °C
• IP rating (with fittings): IP66
• Flame retardancy: Self-extinguishing (UL94 V2)
• Halogen-free: Yes

Recommendations

For a complete protection system, pair with HellermannTyton M25 conduit fittings and accessories to maintain IP66 rating.
