MEAN WELL PSP-600-27 600 W 27 V 22,2 A suljettu virtalähde PFC:llä

Industrial-grade enclosed AC/DC power supply delivering a robust 600 W output at 27 VDC with active PFC and a wide input range of 90–264 VAC. The PSP-600-27 is built for demanding applications where reliable, continuous power is non-negotiable, from factory automation to large-format LED installations.

Advantages

Active power factor correction (PFC) ensures efficient use of mains power and compliance with harmonic current standards. The built-in DC fan with ON/OFF control maintains optimal thermal performance while minimizing noise during low-load operation. Comprehensive protection against short circuit, overload, over voltage, and over temperature safeguards both the supply and connected equipment. Remote ON/OFF and remote sense functions provide flexible system integration, and the 3 kVAC isolation voltage ensures safety in industrial environments.

Suitable for

• Industrial automation and control systems
• LED lighting and signage
• Test and measurement equipment
• Telecommunications infrastructure
• General electronic applications requiring high power density

Key specifications

• Output: 27 VDC, 22.2 A, 600 W
• Input: 90–264 VAC (127–370 VDC), 47–63 Hz
• Efficiency: 88% typical
• Ripple & noise: 150 mVp-p
• Voltage adjustment range: 23.5–30 V
• Operating temperature: -20 to +70 °C
• Protections: short circuit, overload, over voltage, over temperature
• Cooling: built-in DC fan with ON/OFF control
• Certifications: UL60950-1, TUV EN60950-1, CB, CE
• MTBF: >100,000 hours (MIL-HDBK-217F)
• Dimensions (L×W×H): 170 × 120 × 93 mm

Recommendations

For engineers and system integrators who require a dependable, high-efficiency power solution with active PFC and full protection features, the PSP-600-27 is an excellent choice. Its enclosed design and remote control capabilities make it easy to integrate into a wide range of industrial and commercial systems.
