BOPLA yleiskotelo alumiini hopeanharmaa (RAL 7001) 125 x 80 x 57 A 110 01110000.MT1

The BOPLA A 110 universal enclosure stands out with its die-cast aluminium body and silver grey powder coating, offering a robust housing for industrial electronics where durability and a professional appearance matter.

Highlights

• Die-cast aluminium construction
• Silver grey colour, RAL 7001
• External dimensions: 125 mm length, 80 mm width, 57 mm height
• IP 66 ingress protection
• Operating temperature range: -40 °C to +100 °C
• Captive stainless steel lid screws
• Silicone gasket
• Internal mounting bosses for PCBs and components
• Part of the A Series

In daily use

This enclosure suits industrial electronics, control systems, measurement technology, and automation applications. The IP 66 rating protects against dust and powerful water jets, while the wide temperature range ensures reliable performance in demanding environments. The captive screws keep the lid secure during maintenance, and the silicone gasket maintains the seal. Internal bosses simplify mounting of PCBs and components.

Full specifications

• Product type: Universal Enclosure
• Enclosure material: Die-cast Aluminum
• Colour: Silver Grey
• RAL colour code: RAL 7001
• External length: 125 mm
• External width: 80 mm
• External height: 57 mm
• Ingress protection rating: IP 66
• Operating temperature range: -40 °C to +100 °C
• Lid fastening: Stainless steel screws (captive)
• Gasket material: Silicone
• Mounting features: Internal mounting bosses for PCBs/components
• Series: A Series
• Surface finish: Powder-coated
• Application: Industrial electronics, control systems, measurement technology, automation

Final note

A reliable choice for housing sensitive electronics in industrial settings, combining strength, sealing, and ease of assembly.
